Electrical system

Electrical system

KEY

  1. Battery
  2. Starter relay contacts
  3. Starter motor
  4. Main fuse
  5. Ignition switch
  6. Secondary fuses
  7. Voltage regulator
  8. Magneto flywheel
  9. Speed sensor
  10. Instrument panel
  11. MODE button
  12. Turn indicator control
  13. Pre-installation for anti-theft device
  14. Turn indicator switch
  15. Left turn indicator bulbs
  16. Turn indicators warning lights
  17. Right turn indicator bulbs
  18. Stop light
  19. Stop buttons
  20. Starter button
  21. Starter relay coil
  22. High beam warning light
  23. Light switch
  24. Headlight relay
  25. Headlight
  26. Saddle opening actuator
  27. Horn button
  28. Horn
  29. Engine oil pressure warning light
  30. Engine oil pressure sensor
  31. Fuel level transmitter
  32. Fuel gauge
  33. Low fuel warning light
  34. Roll-over sensor
  35. Engine stop switch
  36. Immobilizer LED
  37. Left front daylight running light
  38. Right front daylight running light
  39. Rear daylight running light
  40. License plate light
  41. Injector
  42. Idle valve
  43. Engine speed sensor
  44. Engine temperature sensor
  45. Lambda probe
  46. Fuel pump
  47. H.V. coil
  48. Injection warning light
  49. Throttle body position
  50. Diagnostics socket
  51. Immobilizer antenna
  52. Injection ECU

Cable colour:

Az = Sky blue
Bi = White
Ar = Orange
Gi = Yellow
BL = Blue
Ma = Brown
Ne = Black
Rs = Red
Ro = Pink
Ve = Green
Vi = Violet
Gr = Grey
